Pressure Restricting Valve

Description

Designed to reduce excess line Pressure.

Simple and can be used a stand-alone pressure restricting device

The opening of the Valve is Controlled which restricts the volume of water and thereby lowers the pressure of water

Valves are similar to Standard Landing valves but with a specially designed mechanism incorporated into the stem and bonnet to limit how far the valve can be opened. The valve design has no ability to reduce outlet pressure under no-flow conditions.

If low supply pressure conditions should arise the adjustable gauge stem can by overridden by removal of stop pin that would allow full opening of the valve and unrestricted flow of water .

Unlike pressure regulating type valves, pressure restricting valves have no effect on the static pressure of a system.

Gunmetal Construction for Corrosion Resistance and Sea Water Application

Available in V alve Size 1.5 Inches and 2.5 Inches

Outlet – Threaded / British Standard Instantaneous / Russian Gost / Storz
